Series 15i/150i - Model A Connection manual (Hardware) Page 349

Connection manual (Hardware)
9. FANUC INTELLIGENT TERMINAL
B–63323EN/03
338
Item Specification
Central processing unit MMX–Pentium 166MHz
Realtime clock Precision of "3 minutes per month
Memory Either of the 32MB or 64MB DIMM module
Display
LCD panel 10.4” color LCD panel (640 480 dots, 4096 colors) or
12.1” color LCD panel (800 600 dots, 4096 colors)
Touch panel Option
Soft keys Option
Hard disk unit 3.5” hard disk unit, 3.2GB (to be installed at the rear of the MDI or FA full keyboard)
I/O
PCMCIA card 1 port (Type I or II slot, PCMCIA2.1)
port
Serial port 1 1 port (cannot be used if the touch panel is attached)
Serial port 2 1 port
Full keyboard 1 port (PS/2–compatible)
Mouse 1 port (PS/2–compatible)
Floppy disk 1 port (PC/AT–compatible)
Parallel port 1 port (unidirectional mode)
ISA expansion slot Two 16–bit ISA half–size slots (may not be used if an 8–bit ISA board is used)
Dimensional drawing of the
basic unit
290x220 mm (10.4” LCD type)
340x280 mm (12.1” LCD type)
Dimensional drawings of the
MDI and FA full keyboard
290 220 mm (vertical installation type for the 10.4” LCD type)
230 220 mm (horizontal installation type for the 10.4” LCD type)
340 220 mm (vertical installation type for the 12.1” LCD type)
230 280 mm (horizontal installation type for he 12.1” LCD type)
Weight
10.4” LCD type 3.1 kg (MMX–Pentium intelligent terminal)
3.5 kg (3.5” HDD–installed FA full keyboard, vertical installation type)
2.9 kg (3.5” HDD–installed MDI, vertical installation type)
2.7 kg (3.5” HDD–installed MDI, horizontal installation type)
12.1” LCD type 4.0 kg (MMX–Pentium intelligent terminal)
3.7 kg (3.5” HDD–installed FA full keyboard, vertical installation type)
3.2 kg (3.5” HDD–installed MDI, vertical installation type)
3.1 kg (3.5” HDD–installed MDI, horizontal installation type)
9.3
HARDWARE
SPECIFICATIONS
