C. 20–PIN INTERFACE CONNECTORS AND CABLES

B–63323EN/03

478

Strand wire press–mount connector :

With this connector, #28AWG wires are

press–connected to each pin at the same time.

The cost of producing a cable/connector

assembly with this connector model is much

lower than with connectors designed for

crimping or soldering.

Also, the following connector housing has

been newly developed for use with the i

series.

Connector model (manufacturer) Supplementary description

FI–20–CV7 (Hirose) Low connector housing, more compact than conventional models. The housing

can be fastened to a board–mounted connector by means of a screw lock. It is

intended mainly for connecting the board–mounted connectors used on the main

and option boards of the LCD–mounted type i series (see Section B.3.2). Note that

this connector housing cannot be used for conventional board–mounted

connectors.

Soldering type connector : Details of soldering type connectors and their

housings are summarized below.

Table C (a) Details of soldering type connectors and housings

D Connectors

Connector model (manufacturer) Supplementary description

PCR–E20FS (Honda) Soldering type connector for general signals. This is suitable for producing cable

assemblies in small quantities, as well as on–site.

FI40–20S (Hirose) Equivalent to Honda PCR–E20FS

FI40B–20S (Hirose)

(formerly, FI40A–20S)

Has the same number of pins as the FI40–20S, but features a wider soldering pitch,

facilitating soldering and enabling the use of thicker wires. Its reinforced pins allow

wires as thick as #17AWG to be soldered to the FI40B–20S (wires no thicker than

#20AWG can be used with the FI40A–20S). Note, however, that a thick wire, such

as #17AWG, should be used with a more robust housing like the FI–20–CV6.

FI40B–2015S (Hirose)

(formerly, FI40–2015S)

Features a wider soldering pitch, attained by using the space provided by thinning

out some pins. Also features tougher pins, compared with its predecessor, the

FI40–2015S. These pins can be soldered to wires as thick as #17AWG, provided

that the cable diameter does not exceed 8.5 mm.

C.3

CABLE

CONNECTORS
