Power Mate 0 Connection manual Page 128

Connection manual
2. SIGNAL LIST
B–63443EN/02
PMC INTERFACE
118
Signal
direction
Group Signal name Symbol (address)
CNC
↓
PMC
CNC
↑
PMC
Refer
ence
:
1 CNC ready signal MA (F001#7) f 3.1
Servo ready signal SA (F000#6) f 3.2
:
2 Emergency stop signal
:
ESP (G008#4, X0000#4, X1000#4) f 4.1
External reset signal ERS (G008#7) f 4.2
Reset & rewind signal RRW (G008#6) f 4.3
Over travel limit signal *+L1, *+L2 (G114#0, #1)
*–L1, *–L2 (G116#0, #1)
f 4.4
:
3 Alarm signal AL (F001#0) f 5.1
Battery alarm signal BAL (F001#2) f 5.2
Reset signal RST (F001#1) f 5.3
Rewinding signal RWD (F000#0) f 5.4
Moving direction signals MVD1 (F106#0), MVD2 (F106#1) f 5.5
In–position signals INP1 (F104#0), INP2 (F104#1) f 5.6
Threading signal THRD (F002#3) f 5.7
:
4 Mode select signal MD1 (G043#0), MD2 (G043#1),
MD4 (G043#2)
f 6.1
DNC operation select signal DNCI (G043#5) f 6.1
Manual data input (MDI) check signal MMDI (F003#3) f 6.2
Automatic operation (MEM) check signal MMEM (F003#5) f 6.2
DNC operation select (RMT) check signal MRMT (F003#4) f 6.2
Memory edit (EDIT) check signal MEDT (F003#6) f 6.2
Manual handle step feed (HANDLE/STEP)
check signal
MH (F003#1) f 6.2
Jog feed (JOG) check signal MJ (F003#2) f 6.2
Manual reference position return check sig-
nal
MREFN (F004#5) f 6.2
:
5 Feed axis direction select signal +J1, +J2 (G100#0, #1),
–J1, –J2 (G102#0, #1)
f 7.1
Manual feedrate override signal
:
JV0 to
:
JV15 (G010 ,G011) f 7.2
Manual rapid traverse select signal RT (G019#7) f 7.3
Rapid traverse override signal ROV1 (G014#0), ROV2 (G014#1) f 7.4
Manual absolute signal
:
ABSM (G006#2) f 7.5
:
6 Interlock signal
:
IT (G008#0) f 8.1
Each axis interlock signal
:
IT1,
:
IT2 (G130#0, #1) f 8.2
2.1
I/O SIGNAL LIST
(ORDER OF GROUP)
