Power Mate 0 Connection manual Page 339

Connection manual
B–63443EN/02
H. DESCRIPTION OF PARAMETERS
APPENDIX
329
5002 LWM LD1
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
LD1 Offset number of tool offset
0 : Specified using the lower two digits of a T code
1 : Specified using the lower one digit of a T code
LWM Tool offset
0 : is done in the T code block
1 : is done together with the axis movement
5003 LVC CCN
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
CCN When automatic reference position return (G28) is specified
in tool nose radius compensation :
0 : The tool nose radius compensation vector is cancelled in
movement to an intermediate position.
1 : The tool nose radius compensation vector is not cancelled
in movement to an intermediate position, but is cancelled
in movement to the reference position.
LVC Offset value of tool offset
0 : Not cleared, but held by reset
1 : Cleared by reset
5004 ORC
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
Data type: Bit
ORC Tool offset value
0 : Set by the diameter specification
(Can be set in only the axis under diameter programming)
1 : Set by the radius specification
5005 CNI
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
CNI On the offset screen, Y–axis offset screen, and macro screen,
the [INP.C] soft key is:
0: Used.
1: Not used. (The [INP.C] soft key is not displayed.)
H.14
PARAMETERS OF
TOOL
COMPENSATION
