Power Mate 0 Connection manual Page 131

Connection manual
B–63443EN/02
2. SIGNAL LISTPMC INTERFACE
121
Symbol Signal name PMC address
:
ABSM Manual absolute signal G006#2
AFL Auxiliary function lock signal G005#6
AL CNC alarm signal F001#0
BAL Battery alarm signal F001#2
BDT Optional block skip signal G044#0
BDTO Optional block skip (software operator’s panel) F075#2
BGEACT Background editing signal F053#4
CSS Constant speed signal F002#2
CUT Signal under cutting F002#6
:
DEC1,
:
DEC2 Reference position return deceleration signal X0000#5, X0001#5,
X1000#5, X1001#5
DEN Distribution end signal F001#3
DNCI DNC operation select signal G043#5
DPL0 to DPL2 Screen status signal F254#0 to #2
DRN Dry run signal G046#7
DRNO Dry run signal (software operator’s panel) F075#5
ENB Spindle enable signal F001#4
ERS External reset signal G008#7
:
ESP Emergency stop signal G008#4, X0000#4,
X1000#4
EXRD External read start signal G058#1
EXSTP External read/punch stop signal G058#2
EXWT External punch start signal G058#3
FIN End signal G004#3
:
FLWU Follow–up signal G007#5
:
FV0 to
:
FV7
Feedrate override signal G012
:
FV0O to
:
FV7O
Feedrate override signal (software operator’s panel) F078
GR1, GR2 Gear selection signal G028#1, #2
HS1A, HS1B, HS2A,
HS2B
Manual handle feed axis select signal G018#0, #1, #4, #5
2.2
I/O SIGNAL LIST
(ORDER OF
SYMBOL)
