Power Mate 0 Connection manual Page 324

Connection manual
H. DESCRIPTION OF PARAMETERS
B–63443EN/02
APPENDIX
314
DRL Relative position
0: The actual position displayed takes into account tool
compensation.
1: The programmed position displayed does not take into
account tool compensation.
DAL Absolute position
0: The actual position displayed takes into account tool
compensation.
1: The programmed position displayed does not take into
account tool compensation.
3105 DPS DPF
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
DPF Display of the actual speed on the current position display
screen and program check screen of CRT
0: Not displayed
1: Displayed
DPS Specifies whether the actual spindle speed and T code are
constantly displayed when a CRT is being used.
0: Not displayed constantly
1: Displayed constantly
3107 MDL SOR NAM
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
NAM Program list of CRT
0: Only program numbers are indicated.
1: Program numbers and program names are indicated.
SOR Display of the program directory of CRT
0: Programs are listed in the order of registration.
1: Programs are listed in the order of program number.
MDL Specifies whether the continuous state is to be displayed on
the program display screen of CRT.
0: Not displayed
1: Displayed (in the MDI mode only)
3111 NPA MSC SVS
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
SVS Servo setting screen of CRT
0: Not displayed
1: Displayed
