Power Mate 0 Connection manual Page 227
Connection manual
B–63443EN/02
22. SOFTWARE OPERATOR’S PANELPMC INTERFACE
217
The software operator’s panel substitutes commands sent from the
CRT/MDI for some operation switches on the machine tool operator’s
panel (See Operator’s Manual (B–63444EN) for details). With this
option, output signals are sent from the software operator’s panel, through
the CNC, to the PMC, which converts them to input signals and sends
them back to the CNC, generating the desired action. The correspondence
between output and input signals is shown in Table 22.1.
Table 22.1 Correspondence between Input and Output Signals
Signal name
CNC → PMC PMC → CNC
Program protect signal KEYO<F075#6> KEY
Rapid traverse override signal ROV1O<F076#4>
ROV2O<F076#5>
ROV1
ROV2
Manual handle feed axis select HS1AO<F077#0>
HS1BO<F077#1>
HS1A
HS1B
Dry run signal DRNO<F075#5> DRN
Reference position return signal ZRNO<F073#4> ZRN
Mode selection signal MD1O<F073#0>
MD2O<F073#1>
MD4O<F073#2>
MD1
MD2
MD4
Movement amount select signal in manu-
al handle feed (Incremetal feed signal)
MP1O<F076#0>
MP2O<F076#1>
MP1
MP2
Jog feedrate setting signal *JV0O to *JV15O<F079,F080> *JV0 to *JV15
Cutting feedrate override signal *FV0O to *FV7O<F078> *FV0 to *FV7
Machine lock signal MLKO<F075#4> MLK
Single block signal SBKO<F075#3> SBK
Optional block skip signal BDTO<F075#2> BDT
Feed hold signal *SPO<F075#7> *SP
Jog rapid traverse signal RTO<F077#6> RT
Manual feed direction select signal +J1O, –J1O,+J2O, –J2O
<F081#0, #1, #2, #3>
+J1, –J1, +J2, –J2
22.1
SOFTWARE
OPERATOR’S PANEL
SIGNALS (OUTPUT)
<F073 TO F081>
