19. TOOL FUNCTION
PMC INTERFACE
209
#7 #6 #5 #4 #3 #2 #1 #0
3290 WOF
[Data type] Bit
WOF Setting the tool wear compensation value by MDI key input is:
0 : Not disabled
1 : Disabled (With parameter No. 3294 and No. 3295, set the offset
number range in which updating the setting is to be disabled.)
3294 Start number of tool offset values whose input by MDI is disabled
3295 Number of tool offset values (from the start number) whose input by MDI is
disabled
[Data type] Word
When the modification of tool offset values by MDI key input is to be
disabled using bit 0 (WOF) of parameter No. 3290, parameter Nos. 3294
and 3295 are used to set the range where such modification is disabled.
In parameter No. 3294, set the offset number of the start of tool offset
values whose modification is disabled. In parameter No. 3295, set the
number of such values.
Example:
The following setting disables the modification of both the tool
compensation values corresponding to offset numbers 100 to 110:
Bit 0 (WOF) of parameter No. 3290 = 1 (Disables tool compensation
value modification.)
Parameter No. 3294 = 100
Parameter No. 3295 = 11
#7 #6 #5 #4 #3 #2 #1 #0
5004 ORC
[Data type] Bit
ORC Tool offset value
0 : Set by the diameter specification (Can be set in only the axis under
diameter programming)
1 : Set by the radius specification
#7 #6 #5 #4 #3 #2 #1 #0
5006 OIM
[Data type] Bit
OIM When the unit is switched between the inch and metric systems, automatic
tool compensation value conversion is:
0 : Not performed
1 : Performed
Parameter
