Power Mate 0 Connection manual Page 369
Connection manual
B-63443EN/02-2
7/15
EDIT
DATE DESIG. DESCRIPTION
FANUC Power Mate 0 Connection Manual
Addition of external I/O device control Expansion
TITLE
DRAW.NO.
CUST.
SHEET
01
011128 New design
Diagnosis data select signal
EDGN<G251#7>
[TYPE]
input signal
[FUNCTION]
By setting this signal, diagnosis data are selected as the input/output data.
[ACTION]
Following action is carried out when this signal is turned to “1”.
•
Input motions
Diagnosis data are selected as the input/output data.
Diagnosis data are inputted from I/O device.
NOTE
Only nonvolatile memory and internal memory fields of PMC, which are D0000
∼
∼∼
∼
D1859
and R0000
∼
∼∼
∼
R0999, can be inputted.
•
Output operation
Specified number of Diagnosis data are outputted into I/O device from first
number in order. The first number of diagnosis data that are outputted is set
in the signals of EDG0
∼
EDG15. And number of data is set in the signals of
EDN0
∼
EDN15. But the output is not started when the first number that is
set in the signals of EDG0
∼
EDG15 is out of range, or the number of data
that is specified in the signals of EDN0
∼
EDN15 is 0.
N
data number
P
data
;
N
data number: Sum of address number and a numerical value fixed by each
address is set after
N
. The range of
N20000
∼
N49999
is used
as a data number.
Date number = specified value by each address + address;
P
data: A value is specified after
P
In case of diagnosis data, data type depends on data number.
In case of PMC data, the data is 8-digit binary value after
P
.
A data that is not defined is not outputted.
In case of axis type diagnosis data:
N
data number
A1
P
data
A2 P
data
A1
,
A2
: In case of only axis type diagnosis data, an axis number is outputted as
a numerical value after
A
.
A1
: first axis,
A2
: second axis…
