Power Mate 0 Connection manual Page 320

Connection manual
H. DESCRIPTION OF PARAMETERS
B–63443EN/02
APPENDIX
310
3001 MHI RWM
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
RWM Specifies how the rewind in-progress signal (RWD) is to be
output.
0: The RWD signal is output with the reset and rewind signal
(RRW) only when the tape reader is being rewound.
1: The RWD signal is output with the reset and rewind signal
(RRW) when the tape reader is being rewound or
programs in memory are being rewound.
MHI Exchange of strobe and completion signals for the M, S, and
T code.
0: Normal (FIN : G004.3 is used)
1: High-speed (MFIN : G005.0 is used, SFIN : G005.2 is
used, TFIN : G005.3 is used.)
3003 DEC ITX ITL
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
ITL Interlock signal
0: Enabled
1: Disabled
ITX Interlock signals for the axes
0: Enabled
1: Disabled
DEC Deceleration signal (*DEC1 to *DEC2) for manual reference
position return
0: Deceleration is applied when the signal is 0.
1: Deceleration is applied when the signal is 1.
3004 OTH
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
OTH The overtravel limit signal is:
0: Checked
1: Not checked
H.9
PARAMETERS OF
DI/DO
Previous page
Next page
