Power Mate 0 Connection manual Page 329
Connection manual
B–63443EN/02
H. DESCRIPTION OF PARAMETERS
APPENDIX
319
3401 GSC GSB DPI
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
DPI When a decimal point is omitted in an address that can include
a decimal point
0: The least input increment is assumed.
1: The unit of mm, inches, or s is assumed. (Pocket
calculator type decimal point input)
GSB, GSC The G code system is set.
GSC GSB G code
0 0 G code system A
0 1 G code system B
1 0 G code system C
3402 CLR G91 G01
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
G01 Mode entered when the power is turned on or when the control
is cleared
0: G00 mode (positioning)
1: G01 mode (linear interpolation)
G91 When the power is turned on or when the control is cleared
0: G90 mode (absolute command)
1: G91 mode (incremental command)
CLR Reset button on the CRT/MDI panel, external reset signal,
reset and rewind signal, and emergency stop
0: Cause reset state.
1: Cause clear state.
3404 EOR M02
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
M02 When M02 is specified in memory operation
0: M02 is sent to the machine, and the program is positioned
at its beginning automatically. As completion signal FIN
is returned without resetting or without resetting and
rewinding, the program is restarted from the beginning.
1: M02 is only sent to the machine. The program is
positioned at its beginning by the reset and rewind signal.
EOR 0: An alarm is issued (PS5010, program end) when an EOR
(%, or end of record) is read during program execution.
1: An alarm is not issued (automatic operation stops and a
reset occurs) when an EOR (%, or end of record) is read
during program execution.
H.11
PARAMETERS OF
PROGRAMS
