H. DESCRIPTION OF PARAMETERS
B–63443EN/02
APPENDIX
330
5006 TGC OIM
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
OIM When the unit is switched between the inch and metric
systems, automatic tool offset value conversion is:
0 : Not performed
1 : Performed
TGC When a T code is specified in a block containing G50, G04,
or G10:
0 : No alarm occurs.
1 : P/S alarm No.245 occurs.
5008 CNC CNI
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
CNI Interference check for tool nose radius compensation is:
0 : Performed
1 : Not performed
CNC During interference check for tool nose radius compensation,
when the direction of movement after application of the offset
differs from the programmed direction by between 90_ and
270_:
0 : An alarm is issued.
1 : No alarm is issued.
5010
Limit value that ignores the vector when a tool moves on the outside of a
corner during tool nose radius compensation
Data type: Word
Unit of data:
Increment system Least input increment Unit
Input in mm 0.001 mm
Input in inches 0.0001 inch
Valid data range: 0 to 16383
This parameter sets the limit value that ignores a slight movement
occurring when a tool moves on the outside of the corner during tool
nose radius compensation.
