Power Mate 0 Connection manual Page 342
Connection manual
H. DESCRIPTION OF PARAMETERS
B–63443EN/02
APPENDIX
332
6000 SBM
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
SBM Custom macro statement
0: Not stop the single block
1: Stops the single block
6001 CLV CCV TCS CRO PRT
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
PRT Reading zero when data is output using a DPRINT command
0: Outputs a space
1: Outputs no data
CRO ISO code in the B/D PRINT mode
0: Outputs only LF after data is output
1: Outputs LF and CR after data is output
TCS Custom macro (subprogram)
0 : Not called using a T code
1 : Called using a T code
CCV Custom macroGs common variables Nos. 100 to 149
0: Cleared to <vacant> by reset
1: Not cleared by reset
CLV Custom macroGs local variables Nos. 1 to 33
0: Cleared to <vacant> by reset
1: Not cleared by reset
6010 *7 *6 *5 *4 *3 *2 *1 *0
6011 =7=6=5=4=3=2=1=0
6012 #7 #6 #5 #4 #3 #2 #1 #0
6013 [ 7 [ 6 [ 5 [ 4 [ 3 [ 2 [ 1 [ 0
6014 ] 7 ] 6 ] 5 ] 4 ] 3 ] 2 ] 1 ] 0
(Bit)#7 #6 #5 #4 #3 #2 #1 #0
Data type: Bit
*0 to *7 : Set the pattern of an EIA code indicating *.
=0 to =7 : Set the pattern of an EIA code indicating =.
#0 to #7 : Set the pattern of an EIA code indicating #.
[ 0 to [ 7 : Set the pattern of an EIA code indicating [.
] 0 to ] 7 : Set the pattern of an EIA code indicating ].
NOTE
The numeral of a suffix indicates the bit position in a code.
H.15
PARAMETERS OF
CUSTOM MACROS
