Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 254

Maintenance manual
B–63525EN/02
2. LCD–MOUNTED TYPE i SERIES
HARDWARE
224
Name RemarksIDDrawing number
Display control card
(7.2
″ monochrome LCD, graphic function,
embedded Ethernet function)
A20B–3300–0283 00
Display control card
(9.5
″ monochrome LCD, embedded Ethernet
function)
A20B–3300–0300 07
Display control card
(7.2
″ monochrome LCD, embedded Ethernet
function)
A20B–3300–0301 03
Display control card
(9.5
″ monochrome LCD)
A20B–3300–0302 07
Display control card
(7.2
″ monochrome LCD)
A20B–3300–0303 03
Axis control card
(2 axes)
A20B–3300–0033 00 Applicable servo software:
Series 9090
21i, Loader control
Axis control card
(4 axes)
A20B–3300–0032 01 Applicable servo software:
Series 9090
21i, Loader control
Axis control card
(2 axes)
A20B–3300–0243 08 Applicable servo software:
Series 90B0
Axis control card
(4 axes)
A20B–3300–0242 08 Applicable servo software:
Series 90B0
Axis control card
(6 axes)
A20B–3300–0241 08 Applicable servo software:
Series 90B0
Axis control card
(8 axes)
A20B–3300–0240 08 Applicable servo software:
Series 90B0
Axis control card
(4 axes, high–speed HRV)
A20B–3300–0248 08 Applicable servo software:
Series 90B0
Axis control card
(6 axes, high–speed HRV)
A20B–3300–0245 08 Applicable servo software:
Series 90B0
Axis control card
(8 axes, high–speed HRV)
A20B–3300–0244 08 Applicable servo software:
Series 90B0
Axis control card
(Learning–control axis control)
A20B–3300–0246 08 Applicable servo software:
Series 90B3/90B7
Axis control card
(Learning–control axis control, high–speed HRV)
A20B–3300–0247 08 Applicable servo software:
Series 90B3/90B7
Power supply unit A20B–8100–0720 –
FROM/SRAM module
(FROM 16MB, SRAM 1MB)
A20B–3900–0160 FROM: C1
SRAM: 03
FROM/SRAM module
(FROM 16MB, SRAM 2MB)
A20B–3900–0161 FROM: C1
SRAM: 04
FROM/SRAM module
(FROM 16MB, SRAM 3MB)
A20B–3900–0162 FROM: C1
SRAM: 05
