Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 64

Maintenance manual
1. DISPLAY AND OPERATION
B–63525EN/02
34
CAUTION
1 In the case of an NMI on other than the main board, the
registers of detail display screen 1, and the contents of detail
display screen 2 and detail display screen 3 are displayed.
SYSTEM ALARM HISTORY O1234 N12345
2 2001–03–11 07:23:07 BDH1–01(1/1)
972 NMI OCUURRED IN OTHER MODULE
SLOT> 02
0080415F
<1> <2>
EDIT **** *** *** 08:20:52
[ SELECT ][ RETURN ][ CLEAR ][ ][ ]
(Detail display screen 5)
<1> NMI occurrence slot number
<2> Message address set with the NMI occurrence slot (string address)
SYSTEM ALARM HISTORY O1234 N12345
2 2001–03–11 07:23:07 BDH1–01(1/1)
900 ROM PARITY
00000000 00000000
<1>
EDIT **** *** *** 08:20:52
[ SELECT ][ RETURN ][ CLEAR ][ ][ ]
(Detail display screen 6)
<1> ROM parity cause
Basic ROM 2F(h). . . . . . . . . . . . . . . . . . . . . . . .
(800000A97FFFF)
Additional ROM 40(h). . . . . . . . . . . . . . . . . . . .
(A00000AA3FFFF)
OMM ROM 80(h). . . . . . . . . . . . . . . . . . . . . . .
Servo ROM 100(h). . . . . . . . . . . . . . . . . . . . . . . .
Built in MMC ROM 200(h). . . . . . . . . . . . . . . . .
Online Custom Screen 400(h). . . . . . . . . . . . . . . .
Previous page
Next page
