APPENDIX

B–63525EN/02

A. ALARM LIST

871

409

#6 #5 #4 #3

SPE

S2E

S1E

SHE

#3 (SPE) 0 : In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 : In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E) 0 : The second spindle is normal during the spindle serial control startup.

1 : The second spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E) 0 : The first spindle is normal during the spindle serial control startup.

1 : The first spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE) 0 : The serial communications module in the CNC is normal.

1 : The serial communications module in the CNC was detected to have a

fault.

The details of spindle alarm No. 750 are displayed in the diagnosis display

(No. 409) as shown below.

409

#6 #5 #4 #3

SPE

S4E

S3E

SHE

#3 (SPE) 0 : In the spindle serial control, the serial spindle parameters fulfill the

spindle unit startup conditions.

1 : In the spindle serial control, the serial spindle parameters do not fulfill

the spindle unit startup conditions.

#2 (S2E) 0 : The fourth spindle is normal during the spindle serial control startup.

1 : The fourth spindle was detected to have a fault during the spindle

serial control startup.

#1 (S1E) 0 : The third spindle is normal during the spindle serial control startup.

1 : The third spindle was detected to have a fault during the spindle axis

serial control startup.

#0 (SHE) 0 : The serial communications module in the CNC is normal.

1 : The serial communications module in the CNC was detected to have a

fault.

D The details of spindle

alarm No.750

D 1st and 2nd spindles

D 3rd and 4th spindles
