7. INTERFACE BETWEEN CNC AND PMC
B–63525EN/02
516
Symbol
M
series
T
series
Address Signal name
SPSLA G071#2 f f
SPSLB G075#2 f f
SPSLC
Spindle select signal (serial spindle)
G205#2 f f
SPSLD G267#2 f f
SPSTP Spindle stop complete signal G028#6 f –
SPSYC Spindle synchronous control signal G038#2 f f
SPWRN1 to SPWRN9 Spindle warning detail signals F264#0 to F265#0 f f
SRLNI0 to SRLNI3 Group number specification signals G091#0 to #3 f f
SRLNO0 to SRLNO3 Group number output signals F178#0 to #3 f f
SRN Program restart signal G006#0 f f
SRNMV Program restart under way signal F002#4 f f
SRVA G070#4 f f
SRVB G074#4 f f
SRVC
CCW command signal (serial spindle)
G204#4 f f
SRVD G266#4 f f
SSIN G033#6 f f
SSIN2 G035#6 f f
SSIN3
Spindle motor command polarity select signal
G037#6 f f
SSIN4 G273#6 f f
SSTA F045#1 f f
SSTB F049#1 f f
SSTC
Speed zero signal (serial spindle)
F168#1 f f
SSTD F266#1 f f
ST Cycle start lamp signal G007#2 f f
STL Cycle start signal F000#5 f f
STLK Start lock signal G007#1 f –
STRD Input and run simultaneousmode select signal G058#5 – f
STWD Output and run simultaneousmode select signal G058#6 – f
SUCLP Spindle unclamp signal F038#1 f –
SVF1 to SVF8 Servo off signal G126 f f
SWS1 G027#0 f f
SWS2 G027#1 f f
SWS3
Spindle selection signals
G027#2 f f
SWS4 G026#3 f f
SYCAL Phase error monitor signal F044#4 f f
SYN1O to SYN8O Synchronous control under way signals F118 f –
SYN1O to SYN7O Synchronous/composite/superimposed control under way signals F118#0 to #6 F –
SYNC1 to SYNC8 Simple synchronous axis select signal G138 f f
