Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 893

Maintenance manual

Page of 1105

/ 1105

APPENDIX

B–63525EN/02

A. ALARM LIST

863

No. Message Description

360 n AXIS : ABNORMAL CHECKSUM

(INT)

A checksum error occurred in the built–in pulse coder.

361 n AXIS : ABNORMAL PHASE DATA

(INT)

A phase data error occurred in the built–in pulse coder.

362 n AXIS : ABNORMAL REV.DATA

(INT)

A rotation speed count error occurred in the built–in pulse coder.

363 n AXIS : ABNORMAL CLOCK (INT) A clock error occurred in the built–in pulse coder.

364 n AXIS : SOFT PHASE ALARM (INT) The digital servo software detected invalid data in the built–in pulse

coder.

365 n AXIS : BROKEN LED (INT) An LED error occurred in the built–in pulse coder.

366 n AXIS : PULSE MISS (INT) A pulse error occurred in the built–in pulse coder.

367 n AXIS : COUNT MISS (INT) A count error occurred in the built–in pulse coder.

368 n AXIS : SERIAL DATA ERROR

(INT)

Communication data from the built–in pulse coder cannot be re-

ceived.

369 n AXIS : DATA TRANS. ERROR

(INT)

A CRC or stop bit error occurred in the communication data being

received from the built–in pulse coder.

380 n AXIS : BROKEN LED (EXT) The LED of separate detector is erroneous.

381 n AXIS : ABNORMAL PHASE

(EXT LIN)

A phase data error occurred in the separate linear scale.

382 n AXIS : COUNT MISS (EXT) A pulse error occurred in the separate detector.

383 n AXIS : PULSE MISS (EXT) A count error occurred in the separate detector.

384 n AXIS : SOFT PHASE ALARM

(EXT)

The digital servo software detected invalid data in the separate de-

tector.

385 n AXIS : SERIAL DATA ERROR

(EXT)

Communication data from the separate detector cannot be received.

386 n AXIS : DATA TRANS. ERROR

(EXT)

A CRC or stop bit error occurred in the communication data being

received from the separate detector.

387 n AXIS : ABNORMAL ENCODER

(EXT)

An error occurs in the separate detector. For details, contact the

manufacturer of the scale.

The details of serial pulse coder alarm are displayed in the diagnosis

display (No. 202 and No.203) as shown below.

202

CSA

BLA

PHA

PCA

BZA

CKA

SPH

#6 (CSA) : The serial pulse coder is defective. Replace it.

#5 (BLA) : The battery voltage is low. Replace the batteries.

#4 (PHA) : The serial pulse coder or feedback cable is defective. Replace the serial

pulse coder or cable.

#3 (PCA) : The serial pulse coder is defective. Replace it.

#2 (BZA) : The pulse coder was supplied with power for the first time.

Make sure that the batteries are connected.

Turn the power off, then turn it on again and perform a reference position

return.

#1 (CKA) : The serial pulse coder is defective. Replace it.

#0 (SPH) : The serial pulse coder or feedback cable is defective. Replace the serial

pulse coder or cable.

(5) Serial pulse coder

(SPC) alarms

D The details of serial

pulse coder alarm
