Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 429

Maintenance manual
B–63525EN/02
6. INPUT AND OUTPUT OF DATA
399
6
INPUT AND OUTPUT OF DATA
After you change a SRAM module, you must set various data again.
This chapter describes the procedures to input and output the parameters,
the part programs and the tool offset values.
6.1 SETTING PARAMETERS FOR
INPUT/OUTPUT 400. . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 INPUTTING/OUTPUTTING DATA 402. . . . . . . . . . . . .
6.3 INPUT/OUTPUT Super CAPi DATA 411. . . . . . . . . . . . .
6.4 INPUTTING/OUTPUTTING Symbol CAPi T 417. . . . .
6.5 DUMP/RESTORE OF Symbol CAPi T DATA 419. . . . .
6.6 CLEARING Symbol CAPi T DATA 420. . . . . . . . . . . . .
6.7 DATA INPUT/OUTPUT ON THE
ALL IO SCREEN 422. . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.8 DATA INPUT/OUTPUT USING
A MEMORY CARD 437. . . . . . . . . . . . . . . . . . . . . . . . .
