B-63790EN/01 4.DESCRIPTION OF PARAMETERS

- 95 -

1494 Feedrate during reverse movement

[Input type] Parameter input

[Data type] Real

[Unit of data] mm/min, inch/min, degree/min (machine unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] Refer to the standard parameter setting table (C)

(When the increment system is IS-B, 0.0 - +240000.0)

Set the feedrate to use during reverse movement. When set to 0,

reverse movement is performed at the feedrate specified in the

program.

NOTE

This parameter is not effective to blocks in rapid

traverse during reverse movement.

1496 Critical angle in the automatic exact stop check

[Input type] Parameter input

[Data type] Integer

[Unit of data] degree

[Valid data range] 1 - 179

1497 Distance to travel of minute blocks in the automatic exact stop check

[Input type] Parameter input

[Data type] Real

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard

parameter setting table (B) )

(When the increment system is IS-B, 0.0 - +999999.999)

#7 #6 #5 #4 #3 #2 #1 #0

1517 FCC FNW

TDF LA

ROU MED FIN SET

[Input type] Parameter input

[Data type] Bit

#0 SET Specifies whether the automatic setting function is enabled on the

HPCC (SETTING) screen.

0: Enabled.

1: Disabled.

#1 FIN Specifies whether the automatic tuning function (FINE) is enabled on

the HPCC (SETTING) screen.

0: Enabled.

1: Disabled.

#2 MED Specifies whether the automatic tuning function (MEDIUM) is

enabled on the HPCC (SETTING) screen.

0: Enabled.

1: Disabled.
