B-63790EN/01 4.DESCRIPTION OF PARAMETERS

- 127 -

#5 CIN When CCI is 1, the CIN bit specifies the condition under which the

cutting feed parameter defines the cutting-feed effective area.

0: Used only when the next block specifies cutting feed.

1: Always used regardless of the next block.

The relationship of parameter between a rapid and a cutting is

the following graph.

Parameter CIN (No.1800 #5)

Rapid →

Rapid

No.1827

Rapid →

Rapid

No.1827

Rapid →

Cutting

No.1827

Rapid →

Cutting

No.1827

Cutting →

Cutting

No.1827

Cutting →

Cutting

No.1827

Cutting →

Rapid

No.1827

Cutting →

Rapid

No.1827

Rapid →

Rapid

No.1827

Rapid →

Rapid

No.1827

Rapid →

Cutting

No.1827

Rapid →

Cutting

No.1827

Cutting →

Cutting

No.1838

Cutting →

Cutting

No.1838

Parameter

CCI

(No.1800#4)

Cutting →

Rapid

No.1827

Cutting →

Rapid

No.1838

Two parameter of CCI and CIN mentioned above can be applied for Cs axis.

#6 SAK Specifies whether to change the state of the servo ready signal SA

when the VRDY OFF alarm ignore signal DVAL is 1 or when the

VRDY OFF alarm ignore signal for each axis, DVALn, is 1.

0: The servo ready signal SA changes to 0.

1: The servo ready signal SA retains its state of 1.

#7 IVO Specifies whether to release the emergency stop state when an

emergency stop occurs with the VRDY OFF alarm ignore signal

being 1.

0: Does not release the emergency stop state until the VRDY OFF

alarm ignore signal changes to 0.

1: Releases the emergency stop state.

NOTE

Even when the system is reset when the VRDY

OFF alarm ignore signal is at 1 and the motor is

de-energized, the reset state can be released.
