Series 15i/150i - Model B Parameter manual Page 63

Parameter manual
B-63790EN/01 4.DESCRIPTION OF PARAMETERS
- 53 -
#7 WAM WAM In the NC window function, the reading of the current
machine position (machine coordinates with the servo delay and the
acceleration/deceleration delay considered) is:
0: Not performed.
1: Performed.
NOTE
Set the bit to "0" to keep the load on the CNC low
unless the reading is required.
#7 #6 #5 #4 #3 #2 #1 #0
1014 RAP RAM
[Input type] Parameter input
[Data type] Bit axis
#0 RAM Specifies whether to use the axis as the rotation axis for tool axis
direction tool length compensation, three-dimensional handle feed,
and designation direction tool length compensation.
0: Not used as the rotation axis.
1: Used as the rotation axis.
Select two axes from among rotation axes and set them as the rotation
axes for these purposes.
#1 RAP Specifies whether the rotation axis used for tool axis direction tool
length compensation, three-dimensional handle feed, and designation
direction tool length compensation is an ordinary rotation axis.
0: Ordinary rotation axis.
1: Parameter axis. The rotation axis is not controlled in designation
direction tool length compensation.
If this bit is set to 0, absolute coordinates are used as the coordinates
of rotation axes in tool axis direction tool length compensation mode,
and machine coordinates are used in three-dimentional handle feed
mode. If this bit is set to 1, the value set in parameter No. 7516 is used
as the coordinates of the rotation axes.
When there is no rotation axis in the controlled axes, or when there is
only one rotation axis in the controlled axes, set 1 in bit 0 (RAM) and
bit 1 (RAP) of parameter No. 1014 for the linear axes to which non-
existent rotation axes belong, and set an angular displacement in
parameter No. 7516.
(Example 1)
There are linear axes X, Y, and Z, and rotation axes A, B, and C
which rotate about the X-, Y-, and Z-axes, respectively. The tool axis
direction is controlled with the rotation axes A and C.
RAM (No.1014#0)
X0
Y0
Z0
A1
B0
C1
