Series 15i/150i - Model B Parameter manual Page 259

Parameter manual
B-63790EN/01 4.DESCRIPTION OF PARAMETERS
- 249 -
5611 Number of samples of sampling data for obtaining the mean spindle speed
[Input type] Parameter input
[Data type] Integerspindle
[Valid data range] 0 - 4
The mean value of sampling data is used for spindle speed indication,
feed per revolution, and threading so that the effect of fluctuation of
the spindle speed is reduced. Set how many samples of sampling data
are required to obtain the mean.
0: 1 sample
1: 2 samples
2: 4 samples
3: 8 samples
4: 16 samples
NOTE
Usually, set this parameter to 2.
5612 Unit of spindle speed to be output by DO signals
[Input type] Parameter input
[Data type] Integerspindle
[Unit of data] 1/10
-N
min
-1
[Valid data range] 0 - 3
Set the unit of output by the specified spindle speed signal, actual
spindle speed signal, and maximum spindle speed signal.
U
nit of output spindle speed Setting
1 min
-1
0
0.1 min
-1
1
0.01 min
-1
2
0.001 min
-1
3
