4.DESCRIPTION OF PARAMETERS B-63790EN/01

- 160 -

2060 Area override for area 1 in automatic feedrate control by area

2061 Area override for area 2 in automatic feedrate control by area

2062 Area override for area 3 in automatic feedrate control by area

2063 Area override for area 4 in automatic feedrate control by area

[Input type] Parameter input

[Data type] Integer

[Unit of data] %

[Valid data range] 0 to 127

The area overrides for areas 1 to 4 in automatic feedrate control by

area are set as percentages. If 0 is set for an area, the setting for the

area becomes invalid.

The area override is applied to the feedrate resulting from override of

a specified feedrate.

#7 #6 #5 #4 #3 #2 #1 #0

2070 IH3 IH2 IH1

[Input type] Parameter input

[Data type] Bit

NOTE

After this parameter has been set, the power must be

off turned off then back on for the setting to become

effective.

#0 IH1 Specifies whether to use an I/O-Link-connected manual handle for the

first manual handle.

0: Not used. (An ordinary manual handle is used.)

1: Used.

NOTE

When this parameter is set to "1" and the power is

turned off and then on again, if the appropriate

address value is not set for parameter No. 2071, this

parameter is automatically set to "0" so that the I/O-

Link-connected manual handle cannot be used.
