Series 15i/150i - Model B Parameter manual Page 33

Parameter manual
B-63790EN/01 3.INPUTTING AND OUTPUTTING PARAMETERS USING EXTERNAL INPUT/OUTPUT DEVICES
- 23 -
- Integer axis type format
N ***** A ** P ****** A ** P ****** . . . . ;
The numeric value following N represents the parameter number.
The numeric value following A represents the controlled axis number
(1 or above).
The numeric value following P represents the value (integer) of the
parameter.
; is an end of block character (LF for ISO code and CR for EIA code).
Example
N01020A1P88A2P89A3P90A4P66......;
Parameter number 1020
Parameter values
First axis: 88
Second axis: 89
Third axis: 90
Fourth axis: 66
- Integer spindle type format
N ***** S * P ****** S * P ****** . . . . ;
The numeric value following N represents the parameter number.
The numeric value following S represents the controlled axis number
(1 or above).
The numeric value following P represents the value (integer) of the
parameter.
; is an end of block character (LF for ISO code and CR for EIA code).
Example
N05680S1P19S2P19S3P0S4P0;
Parameter number 5680
Parameter values
First spindle: 19
Second spindle: 19
Third spindle: 0
Fourth spindle: 0
