4.DESCRIPTION OF PARAMETERS B-63790EN/01

- 308 -

6113 Limit of travel distance moved with the cylindrical interpolation cutting point

compensation in the previous block unchanged.

[Input type] Parameter input

[Data type] Real

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 1 - 999999999

The following operation is performed, depending on the type of

interpolation:

1) For linear interpolation

If the travel distance in a specified block is smaller than the

value set in this parameter, machining is performed without

changing the cylindrical interpolation cutting point

compensation in the previous block.

2) For circular interpolation

If the diameter of a specified arc is smaller than the value set in

this parameter, machining is performed without changing the

cylindrical interpolation cutting point compensation in the

previous block. Cylindrical interpolation cutting point

compensation is not performed according to a circular

movement.

6114 Limit for assuming the block as a non-movement block in intersection

calculation for tool side compensation (G41.2, G42.2)

[Input type] Parameter input

[Data type] Real

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting

table (A) )

(When the increment system is IS-B, -999999.999 - +999999.999)

When an intersection calculation is made for tool side compensation,

the block is assumed to be a block involving no movement if the

difference in the coordinates of two points on the compensation plane

is smaller than the value set in this parameter. In such a case, an

additional block ahead is read for intersection calculation. Usually, set

a value about 0.01 mm.
