B-63790EN/01 4.DESCRIPTION OF PARAMETERS

- 243 -

5581 Straightness compensation point number of most negative side of move

axis 1

5582 Straightness compensation point number of most negative side of move

axis 2

5583 Straightness compensation point number of most negative side of move

axis 3

5584 Straightness compensation point number of most negative side of move

axis 4

5585 Straightness compensation point number of most negative side of move

axis 5

NOTE

After this parameter has been set, the power must be

off turned off then back on for the setting to become

effective.

[Input type] Parameter input

[Data type] Integer

[Valid data range] From 1280 through 1919 or from 3072 through 3711 depending on

the number of controlled axes is less than or equal to 10 or greater

than 10, respectively.

Specify the straightness compensation point number located at the

most negative position for each move axis.

When the value set in this parameter is out of the data range, an alarm

is issued, and compensation cannot be performed.
