4.DESCRIPTION OF PARAMETERS B-63790EN/01

- 46 -

#7 #6 #5 #4 #3 #2 #1 #0

1004 DSP

[Input type] Parameter input

[Data type] Bit axis

#6 DSP Specifies whether to display axis positions in the position screen and

the program check screen.

0: Display axis positions.

1: Do not display axis positions.

NOTE

When using the electronic gear box function (EGB),

specify 1 for the dummy axis of the EGB to disable

position display.

#7 #6 #5 #4 #3 #2 #1 #0

1005 RMB MLE EDM EDP PLZ

LZ ZRN

[Input type] Parameter input

[Data type] Bit axis

#0 ZRN Specifies whether to issue an alarm if reference position return has

not been performed since power-on and an attempt is made to execute

a command involving movement other than that with G28 during

automatic operation.

0: Issue an alarm ("PS181 ZERO RETURN NOT FINISHED").

1: Do not issue an alarm but execute operation.

#2 ALZ Specifies the method to use for automatic reference position return

(G28).

0: Return to reference position using positioning (rapid traverse).

If reference position return has not been performed since power-on, it

is performed using the same operation sequence for manual

reference position return.

1: Use the same operation sequence as for manual reference

position return.

Usually, set this bit to 0.

#3 PLZ Specifies the condition for presetting the work coordinate system

when manual reference position return is performed.

0: Preset only when in reset state (e.g. OP signal is off).

1: Always preset.

See ZNP, bit 2 of parameter No. 2402, which is common to all axes.

#4 EDP For each axis, specifies whether the external deceleration signal for

the positive direction is valid during cutting feed.

0: Invalid.

1: Valid.

#5 EDM For each axis, specifies whether the external deceleration signal for

the negative direction is valid during cutting feed.

0: Invalid.

1: Valid.
