B-63790EN/01 4.DESCRIPTION OF PARAMETERS
- 343 -
#7 #6 #5 #4 #3 #2 #1 #0
7002 DPG MIN TSE MP
R
MSB MUS
[Input type] Parameter input
[Data type] Bit
#0 MUS Specifies whether to use interrupt-type custom macros.
0: Do not use.
1: Use.
#1 MSB Specifies whether local variables used in the interrupt program are the
same as those in the main program.
0: Local variables are different from those in the main program
(macro type) .
1: Local variables are the same as those in the main program
(subprogram type) .
#2 MPR Specifies M codes that are used to enable or disable interrupt-type
custom macros.
0: M96/M97
1: M code set in a parameter (parameter No. 7033 or No. 7034)
#3 TSE Specifies whether to use an edge trigger or status trigger to accept the
custom macro interrupt signal.
0: Use an edge trigger (rising edge) .
1: Use a status trigger.
#4 MIN Specifies when to execute CNC statements in the interrupt program.
0: Execute CNC statements by interrupting the block being
executed of the interrupted program (type 1) .
1: Execute CNC statements after the current block of the
interrupted program has been executed (type 2) .
#5 DPG Specifies whether to allow G codes with a decimal point to be called.
0: Do not allow.
1: Allow.
#7 #6 #5 #4 #3 #2 #1 #0
7003 KOP DSM ATN
V
N1
[Input type] Parameter input
[Data type] Bit
#0 VN1 In the registration of variable names with the SETVN statement,
0:
Only an alphabetic character is valid as the first character.
1: Either an alphabetic character or digit is valid as the first
character. (FS15B specifications)
If this parameter bit is set to 1, variable names may be registered
using a non-alphabetic character as the first character with the
SETVN command, as in SETVN500[1ST,2ND]. Note,
however, that a variable name cannot be specified instead of a
variable number, as in [#1ST]=100:.
#1 ATN Specifies the return value of the arctangent function ATAN (with two
arguments) .
0: -180° ≤ ATAN[y]/[x] ≤ 180°
1: 0° ≤ ATAN[y]/[x] ≤ 360°
