4.31 SERVICE PARAMETERS (DATA NO. 8000 AND LATER)
#7 #6 #5 #4 #3 #2 #1 #0
8000 NLP PR
A
NAP PWE
[Input type] Setting input
[Data type] Bit
#0 PWE Specifies whether to enable those parameters that cannot be set by
setting input to be set from an external device or the MDI unit.
0: Not enable.
1: Enable.
#1 NAP Specifies whether to switch the screen display to the alarm message
screen automatically when an alarm is issued.
0: Switch.
1: Do not switch.
#2 PRA Specifies whether to issue an alarm when the PWE parameter is set to
1 (to enable parameter setting) .
0: Issue an alarm.
1: Do not issue an alarm.
#3 NLP From P-CODE, the parameters for the macro executor are:
0: Loaded.
1: Not loaded.
Usually, the parameters for the macro executor are initialized to the
values set in P-CODE when the power is turned on. If this bit is set
to 1, none of these parameters will be initialized, except parameters
Nos. 8500, 8501, 8549, and 8550.
#7 #6 #5 #4 #3 #2 #1 #0
8001 SBU
[Input type] Parameter input
[Data type] Bit
#6 SBU Specifies whether to save file SRAM in a batch from the memory card
input/output screen.
0: Do not save.
1: Save.
#7 #6 #5 #4 #3 #2 #1 #0
8010 NCS
[Input type] Parameter input
[Data type] Bit
#0 NCS Specifies whether the setting of parameter No. 8000 is cleared to 0 or
preserved when the power to the NC is turned off.
0: Cleared to 0.
1: Preserved.
