B-63790EN/01 4.DESCRIPTION OF PARAMETERS

- 295 -

#6 NAA If the interference check avoidance function judges that the avoidance

operation will be dangerous or that further interference will occur for

the interference avoidance vector, the following action takes place:

0: An alarm is issued.

If the avoidance operation is determined to be dangerous, alarm

PS0278 is issued.

If further interference for the interference avoidance vector is

determined, alarm PS0279 is issued.

1: The avoidance operation will continue without issuing any

alarm.

NOTE

Normally, this bit should be set to 0.

#7 NAG In the interference check/avoidance function of cutter compensation,

when the length of the gap vector is 0:

0: An avoidance operation is performed.

1: No avoidance operation is performed.

6009 Number of blocks to be read in the cutter compensation mode

[Input type] Setting input

[Data type] Integer

[Valid data range] 3 - 8

Specify the number of blocks to be read in the cutter compensation

mode. If a value equal to or less than 3 is specified, the specification

of 3 blocks is assumed. If a value equal to or greater than 8 is

specified, the specification of 8 blocks is assumed. As more blocks

are read, an overcutting (interference) forecast can be made for much

more blocks ahead. In this case, however, more blocks are read and

analyzed, so that a longer block processing time is required.

This parameter is not enabled immediately when the MDI mode is set

by stopping the cutter compensation mode. The new setting of this

parameter is enabled when the cutter compensation mode is once

cancelled, and the mode is set again.
