4.DESCRIPTION OF PARAMETERS B-63790EN/01

- 54 -

(Example 2)

The controlled axes include only the linear axes X, Y, and Z. By

using the tool attachment, the tool axis is tilted in the same tool axis

direction as when the A- and C-axes are rotated.

RAM (No.1014#0) RAP(No.1014#1) Angle (No.7516)

X 1 1 45.0

Y0 0 0.0

Z 1 1 30.0

#7 #6 #5 #4 #3 #2 #1 #0

1016 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1

[Input type] Parameter input

[Data type] Bit axis

#n PLm ( n = 0 – 7, m = 1 – 8 )

Specify the m-th combination of parallel axes subject to three-

dimensional coordinate conversion.

To set the bit for a combination to 1, be sure to set three bits to 1.

Example)

For a 9-axis configuration of X, Y1, Y2, Z1, Z2, Z3, Z4, Z5, and

If the values of parameter No. 1016 are:

7 6 5 4 3 2 1 0

X 0 0 1 1 1 1 1 1

Y1 0 0 0 0 0 1 1 1

Y2 0 0 1 1 1 0 0 0

Z1 0 0 0 0 0 0 0 1

Z2 0 0 0 0 0 0 1 0

Z3 0 0 0 0 0 1 0 0

Z4 0 0 0 0 1 0 0 0

Z5 0 0 0 1 0 0 0 0

Z6 0 0 1 0 0 0 0 0

then, the first combination is (X,Y1,Z1), the second (X,Y1,Z2),

the third (X,Y1,Z3), the fourth (X,Y2,Z4), the fifth (X,Y2,Z5),

and the sixth (X,Y2,Z6).

This parameter is checked with parameter No. 1022 to see if the three

basic axes or their parallel axes (if parallel axes are specified for

three-dimensional coordinate conversion) correspond correctly. For

this reason, if 1 is set for one axis of this parameter, check the value

of the corresponding axis of parameter No. 1022.
