4.INTERPOLATION FUNCTIONS PROGRAMMING B-63784EN/01

- 122 -

Format

G06.2 [P_ ] K_ IP_ [R_ ] [F_ ] ;

K_ IP_ [R_ ] ;

K_ ;

…

K_ ;

G01…

G06.2 : Start NURBS interpolation mode

P_ : Rank of NURBS curve

IP_ : Control point (Up to the maximum number of

controlled axes can be specified.)

R_ : Weight

K_ : Knot

F_ : Feedrate

Explanation

- NURBS interpolation mode

The NURBS interpolation mode is selected when G06.2 is

programmed. G06.2 is a modal G code of group 01. So, the NURBS

interpolation mode ends when a G code of group 01 other than G06.2

(e.g. G00, G01, G02, G03) is specified.

- NURBS rank

The NURBS rank can be specified with address P. The rank setting, if

any, must be specified in the same block as the first control point. If the

rank setting is omitted, a rank of four (degree of three) is assumed for

NURBS. The valid data range for P is 2 to 4. The P values have the

following meanings:

P2 : NURBS having a rank of two (degree of one)

P3 : NURBS having a rank of three (degree of two)

P4 : NURBS having a rank of four (degree of three)

This rank is expressed by k in the defining expression indicated in the

description of the NURBS curve below. For example, a NURBS curve

having a rank of four has a degree of three. The NURBS curve can be

expressed by the constants t

, t

and t

- Weight

The weight of a control point programmed in a single block can be

defined. When the weight setting is omitted, a weight of 1.0 is assumed.

Weight is always specified as a 9-digit absolute value of the minimum

data unit of the reference axis. For example, if the unit of the reference

axis is set as millimeter input at IS-B, then weight can be specified

within the range -999999.999 to +999999.999.
