B-63784EN/01 PROGRAMMING 4.INTERPOLATION FUNCTIONS

- 137 -

- Simple start command

When bit 0 (EST) of parameter No. 8412 is set to 1, a control point

command can be omitted at the first control point. The knot values of

the first block and the second block are the same, so that the knot

command can be omitted for the first block only.

The NURBS interpolation command format using this function is as

follows:

G06.2 [P_ ] [K_ ] [IP_ ] [R_ ] [F_ ] ;

K_ IP_ [R_ ] ;

K_ ;

G01...

...

G06.2 : NURBS interpolation mode ON

P_ : NURBS curve rank

IP_ : Control point

R_ : Weight

K_ : Knot

F_ : Feedrate

The word enclosed in [ ] is omissible.

If a control point command is omitted in the first block, the current

position where NURBS interpolation is started is the first control point.

Only those axes that are specified at the control point of the second

block are handled as NURBS interpolation axes. So, specify all

symmetric axes for NURBS interpolation.

If a knot command is omitted in the first block, the same value as

specified in the second block is assumed.
