B-63784EN/01 PROGRAMMING 12.PROGRAM CONFIGURATION

- 263 -

12 PROGRAM CONFIGURATION

General

- Main program and subprogram

There are two program types, main program and subprogram.

Normally, the CNC operates according to the main program. However,

when a command calling a subprogram is encountered in the main

program, control is passed to the subprogram. When a command

specifying a return to the main program is encountered in a subprogram,

control is returned to the main program.

Fig.12 (a) Main program and Subprogram

The CNC memory can hold up to 1000 main programs and

subprograms (100 as standard). A main program can be selected from

the stored main programs to operate the machine.

See II-8 in OPERATION for the methods of registering and selecting

programs.

Follow the direction of the

subprogram

Main program Subprogram

Instruction 1

Instruction 2

Instruction n

Instruction 1'

Instruction 2’

Return to the main program

Instruction n+1
