B-65322EN/02 SVM 3.SPECIFICATIONS

- 9 -

3.3 SELECTING CIRCUIT BREAKER, MAGNETIC

CONTACTOR, AND AC LINE FILTER

3.3.1 Selecting Circuit Breaker

Select a circuit breaker based on the continuous current ratings of the

individual motors listed below. When connecting more than one

amplifier, determine the rating of the circuit breaker based on the sum

of the continuous current ratings of the motors.

When the motor accelerates or decelerates rapidly, current about three

times as high as the continuous current rating may flow for

approximately three seconds. So, select a circuit breaker that does

not trip under such current flow conditions.

WARNING

Because of a possibility of cable burning, consider

protection co-ordination of the cables between the

circuit breaker output and the input of each

amplifier and the selected circuit breaker.

Table Input current for continuous output rating

Servo motor

Continuous current

rating with 3-phase

input

[Arms]

(Reference)

Power supply rating

with 3-phase input

[kVA]

(Reference)

Continuous current

rating with

single-phase input

[Arms]

(Reference)

Power supply rating

with single-phase

input

[kVA]

(Reference)

β0.2/5000is

0.2 0.08 0.5 0.12

β0.3/5000is

0.5 0.15 1.1 0.25

β0.4/5000is

0.6 0.20 1.4 0.32

β0.5/5000is

0.9 0.31 2.2 0.49

β1/5000is

1.8 0.62 4.3 1.0

β2/4000is

2.2 0.77 5.4 1.2

β4/4000is

3.3 1.2 8.1 1.9

β8/3000is

5.4 1.9 9.7 2.2

β12/3000is

8.0 2.8 - -

β22/2000is

11.1 3.9 - -

α1/5000i

2.2 0.77 5.4 1.2

α2/5000i

3.3 1.2 8.1 1.9

α4/4000i

6.2 2.2 - -

α8/3000i

7.1 2.5 - -

α12/3000i

13.4 4.6 - -

α22/3000i

17.8 6.2 - -

α2/5000is

3.3 1.2 8.1 1.9

α4/5000is

4.5 1.5 9.7 2.2

α8/4000is

11.1 3.9 - -

α12/4000is

12.0 4.2 - -
