Series 16i/160i/160is/18i/180i/180is/ Descriptions Page 38

Descriptions
B–63522EN/02
2. LIST OF SPECIFICATIONS
GENERAL
10
Item
Series 21i
Series 210i
Series 210is
Series 18i
Series 180i
Series 180is
Series 16i
Series 160i
Series 160isSpecifications
TBMBTBMBMB5TBMB
Stroke limit check before
travel
l l l l l — —
Chuck/tailstock barrier — l — — l — l
Mirror image Each axis f f f f f f f
Follow–up f f f f f f f
Servo–off/mechanical handle
feed
f f f f f f f
Chamfering on/off — f — — f — f
Backlash compensation f f f f f f f
Separate backlash compensa-
tion for rapid traverse and cut-
ting feed
f f f f f f f
Stored pitch error compensation l l l l l l l
Interpolation type pitch error
compensation
Stored pitch error compensation
is necessary.
l l l l l — —
Bi–directional pitch error com-
pensation
Stored pitch error compensation
is necessary.
l l l l l — l
Expansion of points of bi–direc-
tional pitch error compensation
Stored pitch error compensation
and bi–directional pitch error
compensation are necessary.
l l l l l — l
Gradient compensation l l l l l — —
Straightness deviation
compensation
l l l l l — —
Interpolation straightness devi-
ation compensation
Stored pitch error compensation
is necessary.
l l l l l — —
Position switch l l l l l l l
Tool post interference check
(between 2 paths)
S For 2–path system only
S Up to 64 tool offsets are
available for this function.
l l — — l — —
Rotation area interference
check
l l l l l — —
Abnormal load detection l l l l l l l
Fine torque sensing l l l l l — —
Rotary axis control l l l l l — —
High–speed position switch l l l l l — —
Direction decision type high–
speed position switch
l l l l l — —
Linear scale interface with ab-
solute addressing reference
mark
l l l l l l l
Temporary absolute coordinate
system setting
l l l l l — l
Dual check safety l l l l l l l
Operation
Automatic operation (memory) f f f f f f f
DNC operation
Reader/punch interface
required
: : : : : : :
MDI operation f f f f f f f
Scheduling function Only at 1–path : : : : : : :
Note) The items marked with *1 to *8 (including *1–1, *1–2, and *2–1) have notes added. These notes are pro-
vided at the end of this chapter.
