B–63522EN/02

2. CONVERSATIONAL AUTOMATIC

PROGRAMMING FUNCTION FOR

LATHES

AUTOMATIC PROGRAMMING

FUNCTION

453

Symbol CAPi T is a conversational automatic programming function for

lathes. It has the following features:

D Part figures can be input in a batch by using the symbolic keys.

D Even complicated part figures can be input by using the automatic

intersection calculation function.

D The automatic process determination function creates necessary

processes automatically.

D Any cutting direction or area can be specified.

D NC data can be created without superfluous movement, such as cutting

through air.

D By using MTF, NC data suitable for the particular machine being used

can be created.

D Coloring of screens can be set, and soft keys can be displayed to have

a “raised” look.

Symbol CAPi T can be used with the following lathes:

D 1–spindle/1–turret lathe

D 1–spindle/2–turret lathe

D 2–spindle (main spindle and sub spindle)/1–turret lathe

D 2–spindle (main spindle and sub spindle)/2–turret lathes

D Lathe with Y–axis/C–axis machining functions

D Lathe with the function for tilt plane machining by a tool tilt axis

D Lathe with chasing tool

D Vertical lathe

2.1

Symbol CAPi T

2.1.1

Features

2.1.2

Applicable Machines
