  2. FANUC I/O Link-AS-i Converter Connecting Manual

FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 13

Additional Manual
4.2 For AS-i ver. 2.1 (A03B-0817-C002)
Assign 64 byte input and 64 byte output on the I/O Link
Assign name : input OC03I, output OC03O
(It is necessary to assign two groups continuously.)
<Input>
Group XX Group XX+1
X bit 7-4 bit 3-0 X' bit 7-4 bit 3-0
+0 DI #1A Reserved +0 DI #1B Reserved
+1 DI #3A DI #2A +1 DI #3B DI #2B
+2 DI #5A DI #4A +2 DI #5B DI #4B
+3 DI #7A DI #6A +3 DI #7B DI #6B
+4 DI #9A DI #8A +4 DI #9B DI #8B
+5 DI #11A DI #10A +5 DI #11B DI #10B
+6 DI #13A DI #12A +6 DI #13B DI #12B
+7 DI #15A DI #14A +7 DI #15B DI #14B
+8 DI #17A DI #16A +8 DI #17B DI #16B
+9 DI #19A DI #18A +9 DI #19B DI #18B
+10 DI #21A DI #20A +10 DI #21B DI #20B
+11 DI #23A DI #22A +11 DI #23B DI #22B
+12 DI #25A DI #24A +12 DI #25B DI #24B
+13 DI #27A DI #26A +13 DI #27B DI #26B
+14 DI #29A DI #28A +14 DI #29B DI #28B
+15 DI #31A DI #30A +15 DI #31B DI #30B
+16 AS-i Master Status(1) +16 Reserved
+17 AS-i Master Status(2) +17 Reserved
+18 Board Status(1) +18 Reserved
+19 Board Status(2) +19 Reserved
+20 List of Slave(1) #1A - #7A +20 List of Slave(5) #1B - #7B
+21 List of Slave(2) #8A - #15A +21 List of Slave(6) #8B - #15B
+22 List of Slave(3) #16A - #23A +22 List of Slave(7) #16B - #23B
+23 List of Slave(4) #24A - #31A +23 List of Slave(8) #24B - #31B
+24 Command Status +24 Reserved
+25 Command Error Code +25 Reserved
+26 Command Reply Data(1) +26 Command Reply Data(5)
+27 Command Reply Data(2) +27 Command Reply Data(6)
+28 Command Reply Data(3) +28 Command Reply Data(7)
+29 Command Reply Data(4) +29 Command Reply Data(8)
+30 Reserved +30 Reserved
+31 Reserved +31 Reserved
Standard slaves or A slaves are assigned B slaves are assigned in this area.
in this area.
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
13/33
DESCRIPTION DESIG. DATE
02 02.11.22 Yamana This
p
a
g
e is added
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
#2
