7.3 Setting switch
Operation mode
Setting
switch
Configuration mode Protected mode
Display the address number of the slave units
(Next input of the setting switch is not accepted until the display of every
slave is finished.)
DISP
Display every attached slave units at
about one second interval. (disply
LES)
Display every configuration
mismatch slave at about one second
interval. (display the list of
discrepancies between LPS and
LES)
note: nothing is displayed when
there is no configuration mismatch
slave.
Change the operation mode
note: The mode is not changed continuously, even if the SET switch is keep
pressing. Be sure to turn off the switch longer than one second.
SET
When the SET switch is pressed for
more than 5 seconds, current slave
configuration (LPS, ID code, I/O
configuration, Parameter) is
configured, automatic addressing is
enabled, and the mode is changed to
the protected mode. (note 1)
When the SET switch is pressed for
less than 5 seconds, the mode is
changed to the protected mode
without configuring. Also the
automatic addressing is not
available. (note 2)
When the SET switch is pressed for
more than 5 seconds, the mode is
changed to the configuration mode.
When the SET switch is pressed for
less than 5 seconds, the mode is not
changed.
note 1) It can not be configured when the slave with address "0" is attached. Also the
mode can not be changed to the protected mode. Alarm "E5" is displayed on the 7
segments LED.
note 2) The mode is not changed to the protected mode when the slave with address "0"
is attached. Alarm "E5" is displayed on the 7 segments LED.
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
28/33
DESCRIPTION DESIG. DATE
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
