5. Details of I/O Link DI/DO
5.1 input / output data area
5.1.1 For AS-i ver. 2.0 (A03B-0817-C001)
Signal input is assigned on from X+0 to X+15, signal output is assigned on from Y+0 to
Y+15. 1 means ON state and 0 means OFF state.
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
DI of slave address no.1 Reserved X+0
IN4 IN3 IN2 IN1 Reserved Reserved Reserved Reserved
DI of slave address no.3 DI of slave address no.2 X+1
IN4 IN3 IN2 IN1 IN4 IN3 IN2 IN1
:
:
DI of slave address no.31 DI of slave address no.30 X+15
IN4 IN3 IN2 IN1 IN4 IN3 IN2 IN1
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
DO of slave address no.1 Reserved Y+0
OUT4 OUT3 OUT2 OUT1 Reserved Reserved Reserved Reserved
DO of slave address no.3 DO of slave address no.2 Y+1
OUT4 OUT3 OUT2 OUT1 OUT4 OUT3 OUT2 OUT1
:
:
DO of slave address no.31 DO of slave address no.30 Y+15
OUT4 OUT3 OUT2 OUT1 OUT4 OUT3 OUT2 OUT1
EDIT
FANUC LTD
SHEET
DRAW. NO. CUST
TITLE
15/33
DESCRIPTION DESIG. DATE
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
Previous page
Next page
