FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 31

Additional Manual
9．How to use I/O Link - AS-i Converter
9.1 Installation
Note:
1. When the mode is changed to the protected mode, slave configuration is configured and
automatic addressing is enabled.
2. Operation mode is not changed when the power of the I/O Link-AS-i Converter Unit is
turned on/off. Press the SET switch to change the operation mode..
NO
Mount the I/O Link-AS-i Converter, AS-i
power supply and AS-i slave unit
Start
Set the address of AS-i slave unit
Connect AS-i cable
Turn on the power of I/O Link-AS-i Converte
r
and AS-i power supply
Confi
g
uration mode?
Press the SET switch more than 5 seconds to
change to the configuration mode.
Press the DISP switch and check the address
number of currently connected slaves.
Press the SET switch more than 5 seconds to
change to the protected mode.
End
YES
mode LED
"CM"
configuration lit
protected off
These operations can be done
when the I/O Link is not
connected. (In other words,
even if the power of I/O Link -
A
S-i Converter is turned on and
the power of CNC is turned off,
these setting operation can be
done.)
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
31/33
DESCRIPTION DESIG. DATE
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
