FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 33

Additional Manual
10. CE marking
I/O Link-AS-i converter is applied to CE marking.
Because I/O Link-AS-i converter is based on European Standard about AS-i (EN50295),
this unit is not tested for surge immunity.
11. Fuse
The unit has built-in fuse. If a fuse blows, remove the cause, then replace the fuse with a
spare.
Indication Rating Fuse specification
POW is off 1A A60L-0001-0290#LM10
The fuse is on the PC board in the unit.
12.List of units
Ver. of AS-i Unit drawing PCB drawing
Ver2.0 A03B-0817-C001 A20B-2003-0110
Ver2.1 A03B-0817-C002 A20B-2003-0111
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
33/33
DESCRIPTION DESIG. DATE
02 02.11.22 Yamana Out of frame #2 is added
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
#2
#2
