FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 22

Additional Manual
6.6 Details of commands
(1) A parameter value for the specified AS-i slave is transferred to EEPROM of AS-i
converter.
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Y+17 0AH
Y+18
Slave address（01H~1FH, 20H~3FH）Note1) Refer to 24page
Y+19 0 Parameter
Set data
Y+20~Y+21 none
Response
data
X+25 Error code
A parameter value that is written in EEPROM is not transferred to the specified AS-i slave
at execution of command. It is transferred at next power on.
(2) A specified slave parameter value on the EEPROM of AS-i converter is read.
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Y+17 0BH
Y+18
Slave address（01H~1FH, 20H~3FH）Note1) Refer to 24page
Set data
Y+19~Y+21 none
X+25 Error code Response
data
X+26 0 Parameter
(3) A parameter value is transferred to the specified AS-i slave
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Y+17 0CH
Y+18
Slave address（01H~1FH, 20H~3FH）Note1) Refer to 24page
Y+19 0 Parameter
Set data
Y+20~Y+21 none
X+25 Error code Response
data
X+26 0 Parameter
A parameter value is transferred to the specified AS-i slave at execution of command.
However this value is disappeared when AS-i converter is turned off, because this value is
not stored on EEPROM of AS-i converter.
(4) A parameter value is read from the specified AS-i slave
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Y+17 0DH
Y+18
Slave address（01H~1FH, 20H~3FH）Note1) Refer to 24page
Set data
Y+19~Y+21 none
X+25 Error code Response
data
X+26 0 Parameter
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
22/33
DESCRIPTION DESIG. DATE
02 02.11.22 Yamana Out of frame #2 is added
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
#2
#2
#2
#2
