FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 23

Additional Manual
(5) Read actual I/O configuration data and actual ID codes of an addressed slave detected
on the AS-i.
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Y+17 12H
Y+18
Slave address（01H~1FH, 20H~3FH）Note1) Refer to 24page
Set data
Y+19~Y+21 none
X+25 Error code
X+26 0 ID code
Response
data
X+27 0 I/O configuration
(6) Change slave address
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Y+17 17H
Y+18
Old slave address（01H~1FH, 20H~3FH）
Note1) Refer to 24page
Y+19
New slave address（01H~1FH, 20H~3FH）
Note1) Refer to 24page
Set data
Y+20~Y+21 none
Response
data
X+25 Error code
If an AS-i slave with address 0 is connected, this command cannot be executed.
(7) Analog input value is read from the specified AS-i slave
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Set data Y+17 29H
Y+18
Slave address（01H~1FH） Note2) Refer to 24page
Y+19~Y+21 none
Y'+18~Y'+21 none
X+25 Error code
X+26 Ch1 input value (High byte)
X+27 Ch1 input value (Low byte)
X+28 Ch2 input value (High byte)
X+29 Ch2 input value (Low byte)
X'+26 Ch3 input value (High byte)
X'+27 Ch3 input value (Low byte)
X'+28 Ch4 input value (High byte)
Response
data
X'+29 Ch4 input value (Low byte)
Note) This command is only available in AS-i ver. 2.1.
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
23/33
DESCRIPTION DESIG. DATE
02 02.11.22 Yamana Out of frame #2 is added
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
#2
#2
#2
#2
