FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 26
Additional Manual
7.1 LED display
name color meaning
POW Green Power supply to the unit is on. Unit
ERR Red Unit Error (refer to the other LED, 7 segments LED
display or status on the I/O Link about details of error)
RDY Green I/O Link Ready (I/O Link communication available) I/O Link
ALM Red I/O Link Alarm (refer to the 7 segments LED display）
AUP Green AUtomatic address Programming available
The LED lit when the operation mode is the protected
mode and automatic addressing is enabled.
CM Green LED lit: Configuration Mode
LED off: Protected Mode
APF Red AS-i Power supply Fail
AS-i
CER Red Configuration ERror
The LED is lit when the slave configuration detected on
the AS-i cable deviates from the configured
configuration. (LPS､ ID code､ or I/O configuration is
deviated)
7.2 7 segments LED display
LED display meaning
no display Normal operation
E0 AS-i master error
E1 AS-i master EEPROM error
E2 ROM error
E3 RAM error
E5
Command execution error､SET switch execution error
E6 I/O Link slave Watch Dog Alarm
E7 I/O Link RAM error
E8 Watch Dog Alarm1
E9. or "."(dot) of X10 Watch Dog Alarm2
00 - 31 Slave address display (refer to the table below and next page)
"."(dot) of X1 When address of B slave is indicated, this lamp turns on.
88 Initialize operation, mode shifting, AS-i power supply fail,
operation mode normal operation When the setting switch DISP is pressed.
configuration
mode
no display Display every attached slave units at about
one second interval. (LES display)
protected mode The smallest
address number
from configuration
mismatch slaves is
displayed.
Display every configuration mismatch slave
at about one second interval. (display the list
of discrepancies between LPS and LES)
note: nothing is displayed when there is no
configuration mismatch slave.
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
26/33
DESCRIPTION DESIG. DATE
02 02.11.22 Yamana Out of frame #2 is added
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
#2
