FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 16

Additional Manual
5.1.2 For AS-i ver. 2.1 (A03B-0817-C002)
Signal input is assigned on from X+0 to X+15 (group XX) and from X'+0 to X'+15 (group
XX+1), signal output is assigned on from Y+0 to Y+15 (group XX) and from Y'+0 to Y'+15
(group XX+1). 1 means ON state and 0 means OFF state.
<Input>
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
X+0 DI of slave address no.1A Reserved
IN4 IN3 IN2 IN1
Reserved Reserved Reserved Reserved
X+1 DI of slave address no.3A DI of slave address no.2A
IN4 IN3 IN2 IN1 IN4 IN3 IN2 IN1
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
X+15 DI of slave address no.31A DI of slave address no.30A
IN4 IN3 IN2 IN1 IN4 IN3 IN2 IN1
X'+0 DI of slave address no.1B Reserved
IN4 IN3 IN2 IN1
Reserved Reserved Reserved Reserved
X'+1 DI of slave address no.3B DI of slave address no.2B
IN4 IN3 IN2 IN1 IN4 IN3 IN2 IN1
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
X'+15 DI of slave address no.31B DI of slave address no.30B
IN4 IN3 IN2 IN1 IN4 IN3 IN2 IN1
<Output>
address bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Y+0 DO of slave address no.1A Reserved
OUT4
Note)
OUT3 OUT2 OUT1
Reserved Reserved Reserved Reserved
Y+1 DO of slave address no.3A DO of slave address no.2A
OUT4
Note)
OUT3 OUT2 OUT1 OUT4
Note)
OUT3 OUT2 OUT1
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Y+15 DO of slave address no.31A DO of slave address no.30A
OUT4
Note)
OUT3 OUT2 OUT1 OUT4
Note)
OUT3 OUT2 OUT1
Y'+0 DO of slave address no.1B Reserved
Reserved
OUT3 OUT2 OUT1
Reserved Reserved Reserved Reserved
Y'+1 DO of slave address no.3B DO of slave address no.2B
Reserved
OUT3 OUT2 OUT1
Reserved
OUT3 OUT2 OUT1
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Y'+15 DO of slave address no.31B DO of slave address no.30B
Reserved
OUT3 OUT2 OUT1
Reserved
OUT3 OUT2 OUT1
End character (A or B) of slave address no. means sub-address. In case of standard slave,
DI/DO are assigned in group XX.
Note) In case of A/B slave, OUT4 bit is assigned as reserved bit. Then you can not use OUT4
bit.
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
16/33
DESCRIPTION DESIG. DATE
02 02.11.22 Yamana This
p
a
g
e is added
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
Group XX Group XX+1 Group XX Group XX+1
