FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 17
Additional Manual
5.2 AS-i master status
address bit item bit status Condition of flag on
0 Off line phase status 1 : off line
0 : not off line
When the off line phase is
active; configuring process is
executed, or AS-i power supply
fail
1 AS-i power supply
status
1 : Voltage on AS-i line is
too low
0 : normal
AS-i power supply is off or too
low
2 Operation status 1 : Normal operation
0 : initialize operation
normal operation mode; AS-i
communication is possible
3 Operation mode 1 : Configuration mode
0 : Protected mode
configuration mode
4 Status of automatic
addressing
1 : possible
0 : impossible
Automatic addressing can be
executed.
(protected mode, automatic
addressing is enabled and
exactly one slave is currently
out of operation)
5 Reserved
6 Connection of slave
with address 0
1 : connected
0 : not connected
Slave with address 0 is
connected.
X+16
7 Configuration match
status
1 : match
0 : mismatch
Current configuration is same
as configured(desired)
configuration
0 Off line operation
status
1 : off line
0 : not off line
1 Reserved
2 EEPROM status 1 : normal
0 : failure
internal EEPROM of AS-i
master is OK
3 Automatic
addressing enable
status
1 : enabled
0 : not enabled
Automatic addressing is
enabled
X+17
4 -
7
Reserved
5.3 Board status
address bit item bit status
0 AS-i data ready 1 : DI/DO data is valid 0 : DI/DO data is invalid
1 Error status 1 : Error is occurred 0 : normal
2 AS-i master fail 1 : AS-i master fail 0 : normal
3 ROM fail 1 : ROM fail 0 : normal
4 RAM fail 1 : RAM fail 0 : normal
5 Watch Dog Alarm 1 : Watch Dog Alarm 0 : normal
6 Reserved
X+18
7 Reserved
0 - 3 Software edition X+19
4 - 7 Hardware edition
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
17/33
DESCRIPTION DESIG. DATE
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
