FANUC I/O Link-AS-i Converter Connecting Manual Additional Manual Page 14

Additional Manual
<Output>
Group XX Group XX+1
Y bit 7-4 bit 3-0 Y' bit 7-4 bit 3-0
+0 DO #1A Reserved +0 DO #1B Reserved
+1 DO #3A DO #2A +1 DO #3B DO #2B
+2 DO #5A DO #4A +2 DO #5B DO #4B
+3 DO #7A DO #6A +3 DO #7B DO #6B
+4 DO #9A DO #8A +4 DO #9B DO #8B
+5 DO #11A DO #10A +5 DO #11B DO #10B
+6 DO #13A DO #12A +6 DO #13B DO #12B
+7 DO #15A DO #14A +7 DO #15B DO #14B
+8 DO #17A DO #16A +8 DO #17B DO #16B
+9 DO #19A DO #18A +9 DO #19B DO #18B
+10 DO #21A DO #20A +10 DO #21B DO #20B
+11 DO #23A DO #22A +11 DO #23B DO #22B
+12 DO #25A DO #24A +12 DO #25B DO #24B
+13 DO #27A DO #26A +13 DO #27B DO #26B
+14 DO #29A DO #28A +14 DO #29B DO #28B
+15 DO #31A DO #30A +15 DO #31B DO #30B
+16 Command Flag +16 Reserved
+17 Command Code +17 Reserved
+18 Command Parameters(1) +18 Command Parameters(6)
+19 Command Parameters(2) +19 Command Parameters(7)
+20 Command Parameters(3) +20 Command Parameters(8)
+21 Command Parameters(4) +21 Command Parameters(9)
+22 Command Parameters(5) +22 Reserved
+23 Reserved +23 Reserved
+24 Reserved +24 Reserved
+25 Reserved +25 Reserved
+26 Reserved +26 Reserved
+27 Reserved +27 Reserved
+28 Reserved +28 Reserved
+29 Reserved +29 Reserved
+30 Reserved +30 Reserved
+31 Reserved +31 Reserved
Standard slaves or A slaves are assigned B slaves are assigned in this area.
in this area.
EDIT
FANUC LTD
SHEET
DRAW. NO.
CUST
TITLE
14/33
DESCRIPTION DESIG. DATE
02 02.11.22 Yamana This
p
a
g
e is added
FANUC I/O Link-AS-i Converter
Connecting manual
A
-80906E
#2
