PROGRAMMING

B–64124EN/01

19. HIGH SPEED CUTTING

FUNCTIONS

381

The functions listed below are valid in the AI advanced preview

control/AI contour control mode:

⋅ Look–ahead linear acceleration/deceleration before interpolation

⋅ Look–ahead bell–shaped acceleration/deceleration before interpolation

(The option of look–ahead bell–shaped acceleration/deceleration

before interpolation is required.)

⋅ Automatic corner deceleration

⋅ Feedrate clamping by acceleration

⋅ Feedrate clamping by arc radius

⋅ Block overlap

⋅ Advanced preview feed forward

For a cutting feed command in the feed per minute mode, linear

acceleration/deceleration can be applied before interpolation, that is, for

the specified feedrate by reading up to 20 blocks (in the AI advanced

preview control mode) or 40 blocks (in the AI contour control mode) in

advance. With acceleration/deceleration after interpolation, the

interpolated data is changed because acceleration/deceleration is applied

to the data. With acceleration/deceleration before interpolation, the

interpolated data cannot be changed by acceleration/deceleration because

acceleration/ deceleration is applied to the feedrate data before

interpolation. For this reason, the interpolated data can always be applied

to the specified straight line or curve to eliminate machining profile errors

caused by acceleration/deceleration delays.

Linear interpolation,

circular interpolation, etc.

Distribution

pulse

Specified

feedrate

Linear accelera-

tion/deceleration

before

interpolation

Feedrate

calculation

Servo

control

Acceleration/

deceleration

after

interpolation

Interpolation

calculation

D Functions valid in the AI

advanced preview

control/AI contour

control mode

D Look–ahead linear

acceleration/deceleration

before interpolation
